HomeDriversWoofer Peerless NE225W-04 8″ Paper Cone NE Woofer 4 Ohm
Previous product
Peerless by Tymphany 830452 10" XLS Subwoofer ₹16,300.00 ₹13,500.00
Back to products
Next product
Peerless by Tymphany NE315W-04 12" Subwoofer Speaker ₹24,600.00 ₹17,000.00

Peerless NE225W-04 8″ Paper Cone NE Woofer 4 Ohm

₹15,800.00

PRODUCT INFO

This 8 inch 4 ohm member of the NE family has leading-edge transducer technology packaged in a cutting edge, stylistic design. The subwoofers in this family feature an innovative cast aluminium basket design which minimizes acoustic reflections inside the driver, through large basket windows and sculpted basket spokes. The basket also is designed to act as a highly coupled heat sink to the Neodymium-Iron-Boron magnet (NdFeB) motor, so as to improve power handling capacity. An additional heat sink is available to provide extra thermal protection if needed. The cone and dust cap are constructed of natural wood fiber material with proprietary coating formulas & processes, so as to yield high clarity products. The cone designs also utilize pentacone technology for improved frequency response. The voice coil bobbin is titanium, for improved performance. The FEA-designed motor features copper caps to minimize inductance and extend performance to high frequencies. Rounding out the design is a 4-way terminal block connector, for ease of electrical connection.

Download PDF File
Compare
Add to wishlist
Categories: Drivers, Subwoofer, Woofer
Share
  • Description
  • Shipping & Delivery
Description

TECHNICAL SPECIFICATIONS

Driver Size 8 in –
DC Resistance 3.12 Ω ±5.0%
Resonant Frequency 33.15 Hz 15%
Half Space Sensitivity @ 2.83V 90.18 dB ±1.01
Sensitivity @ 1W/1m 87.1 dB ±1.01
Rated Noise Power (IEC 268-5 18.1) 125 W –
Test Spectrum Bandwidth 30Hz – 1.5kHz 12 dB/Oct –
Effective Piston Area 227 cm2 –
Moving Mass 37.2 g –
Motor Force Factor 8.36 T•m –
Voice Coil Inner Diameter 51.32 mm –
Gap Height 8 mm –
Maximum Linear Excursion 7.6 mm –
Ferrofluid Type –
Minimum Impedance 3.9 Ω ±7.5%
Voice Coil Inductance 0.16 mH –
Mechanical Q Factor 9.8 –
Electrical Q Factor 0.35 –
Total Q Factor 0.33 –
Ratio 99.25 fs/Qts –
Energy Bandwidth Product ((1/Qes)•fs) –
Suspension Compliance 619.5 μm/N –
Effective Cone Diameter 17 cm –
Motor Efficiency Factor 22.4 (T•m2)/Ω –
Voice Coil Former Material TiSV –
Driver Mass 1.86 Kg –
Equivalent Volume 44.82 L –
