Peerless by Tymphany TC9FD18-08 3-1/2″ Full Range Paper Cone Woofer
PRODUCT INFO
This TC family 3.5 inch 8 ohm full-range driver,with ferrite magnet, paper cone, rubber surround, and plastic basket with front sealing gasket, is designed to be a cost-effective high performance full range driver. The cone utilizes Tymphany-patented PentaCut NRSC cone technology to help dampen and control cone resonances, optimizing the listening experience. The motor contains a copper cap to lower inductance and distortion. The product was designed with portable and compact applications in mind.
Download PDF File
₹1,350.00 ₹1,500.00
TECHNICAL SPECIFICATIONS
| Driver Size | 3.5 in | – | ||
| DC Resistance | 6.32 Ω | ±5.0% | ||
| Resonant Frequency | 124.86 Hz | 15% | ||
| Half Space Sensitivity @ 2.83V | 84.56 dB | ±1.01 | ||
| Sensitivity @ 1W/1m | 84.4 dB | ±1.01 | ||
| Rated Noise Power (IEC 268-5 18.1) | 30 W | – | ||
| Test Spectrum Bandwidth | 100Hz-20KHz 12 dB/Oct | – | ||
| Effective Piston Area | 36.3 cm2 | – | ||
| Moving Mass | 2.4 g | – | ||
| Motor Force Factor | 3.01 T•m | – | ||
| Voice Coil Inner Diameter | 19.43 mm | – | ||
| Gap Height | 4 mm | – | ||
| Maximum Linear Excursion | 2.6 mm | – | ||
| Ferrofluid Type | – | |||
| Minimum Impedance | 7.75 Ω | ±7.5% | ||
| Voice Coil Inductance | 0.05 mH | – | ||
| Mechanical Q Factor | 2.73 | – | ||
| Electrical Q Factor | 1.33 | – | ||
| Total Q Factor | 0.89 | – | ||
| Ratio | 139.82 fs/Qts | – | ||
| Energy Bandwidth Product ((1/Qes)•fs) | – | |||
| Suspension Compliance | 669.6 μm/N | – | ||
| Effective Cone Diameter | 6.8 cm | – | ||
| Motor Efficiency Factor | 1.4 (T•m2)/Ω | – | ||
| Voice Coil Former Material | ASV | – | ||
| Driver Mass | 0.3 Kg | – | ||
| Equivalent Volume | 1.24 L | – |
| brands | Tymphany |
|---|
TC9FD18-08
| Platform: | Tymphany |
| Driver Type: | Full Range |
| Size: | 3.5 in |
| Motor: | Ferrite |
| Frame: | Plastic Basket |
| Impedance: | 8 Ω |
| Diaphragm: | Paper |
