Peerless by Tymphany BC25SC06-04 1″ Textile Dome Tweeter
The BC family of tweeters features a damped fabric dome for smooth frequency response performance and ferrofluid in the gap of the NdFeB magnet motor,providing enhanced cooling of the voice coil. BC tweeters come with a compact faceplate with recessed mounting holes,and for this driver a finned heat sink has been added to improve power handling.
Download PDF File
Peerless by Tymphany BC25SC08-08 1 Fabric Dome Tweeter 8 Ohm
The Peerless BC25SC08-08 tweeter features an 8 ohm 25 mm voice coil, a damped fabric dome for smooth frequency response performance, a bucking magnet for higher sensitivities, and ferrofluid in the gap of the NdFeB motor, providing enhanced cooling of the voice coil.
Highlights
- Damped fabric dome for smooth frequency response
- Features a bucking magnet for higher sensitivity
- Utilizes ferrofluid for improved power handling
- Rear heat sink for improved heat dispersion
Peerless by Tymphany BC25SC08-08 Fabric Dome Neodymium Tweeter
PRODUCT INFO
This BC family tweeter features a 8 ohm 25 mm voice coil, a damped fabric dome for smooth frequency response performance, a bucking magnet for higher sensitivities, and ferrofluid in the gap of the NdFeB motor, providing enhanced cooling of the voice coil. The tweeter comes with a bucking magnet and a compact faceplate with recessed mounting holes, greatly increasing the sensitivity of the tweeter.A finned heat sink has been added for improved power handling.
Download PDF File
Peerless by Tymphany BC25TG15-04 1″ Silk Dome Tweeter
The BC25SG15-04 1" dome tweeter from Tymphany can meet the most demanding requirements for audio excellence.
Key Features
- Sculpted, recessed-loaded round 4-hole faceplate
- Smooth, extended response and high efficiency
- 1" textile dome
- Ferrofluid cooled voice coil
| Transducer Size (Millimeters) | 25 |
|---|---|
| DC Resistance | 2.99 |
| Resonant Frequency | 1128.01 |
| Half Space Sensitivity | 93.21 |
| Rated Noise Power | 50 |
| Test Spectrum Bandwidth | 1.1kHz - 20kHz |
Peerless by Tymphany BC25TG15-08 1″ Fabric Dome Tweeter 8 Ohm
The BC25SG15-08 1" dome tweeter from Tymphany can meet the most demanding requirements for audio excellence.
Highlights
- Sculpted, recessed-loaded round 4-hole faceplate
- Smooth, extended response and high efficiency
- 1" textile dome
- Ferrofluid cooled voice coil
Peerless by Tymphany BC25TG15-08 Silk Dome Tweeter 8ohms
PRODUCT INFO
This BC family tweeter features a 8 ohm 25 mm voice coil, a damped fabric dome for smooth frequency response performance, and ferrofluid in the gap of the ferrite motor, providing enhanced cooling of the voice coil. The tweeter comes with a compact faceplate with recessed mounting holes, complete with sealing gasket which helps in reducing vibration between baffle and driver.
Download PDF File
Peerless by Tymphany D27TG35-06 1″ Silk Dome Tweeter
This D family tweeter features an 6 ohm 25 mm voice coil, a treated silk dome, large rear chamber for low resonant frequency, and a ferrofluid-cooled ferrite magnet motor. The large motor and rear chamber allow for robust power handling capacity. The tweeter comes with a faceplate with recessed mounting holes, for easy installation into the desired application.
Download PDF File
Peerless by Tymphany DX25TG59-04 1″ Fabric Dome Tweeter
Product Info
This DX family tweeter features a 4 ohm 25 mm ferrofluid-cooled voice coil, a damped silk diaphragm with a large surround roll to produce a low resonant frequency, and a ferrite magnet motor which adds heat sinking for power handling capacity. The faceplate features recessed mounting holes to minimize reflections. Tymphany's DX25TG59-04 tweeter's lightweight diaphragm with large surround structure gives extended high frequency response and superb off-axis characteristics, while the tuned rear chamber and extra-strong 5-hole faceplate yield excellent mechanical damping. Key Features- Extra-strong 5-hole faceplate
- 1" treated soft dome
- Tuned chamber lowers resonance
- Large surround increases range
Download PDF
Peerless by Tymphany H25TG05-08 1 Titanium Dome Tweeter with Waveguide 8 Ohm
The Tymphany H25TG05-08 horn loaded titanium dome tweeter features smooth response from 2,500 to 20,000 Hz and high efficiency, making it an excellent choice for any high efficiency speaker system.
Highlights
- Horn loaded design for increased sensitivity
- Titanium dome for detailed, accurate music reproduction
- Large, Ferrofluid-cooled motor improves power handling
- Treated dome for smooth frequency response
Peerless by Tymphany OX20SC00-04 34 Fabric Dome Tweeter
Tymphany's OX20SC00-04 tweeter features a coated textile diaphragm, high-energy neodymium magnet, and does not include a faceplate.
Highlights
- Faceplate-less design for custom mounting
- Smooth, extended response and high efficiency
- 3/4" textile dome
- Self-shielding neodymium motor
- Low Fs, low distortion
- High efficiency
Peerless by Tymphany XT25SC90-04 1″ Dual Ring Radiator Tweeter
PRODUCT INFO
This member of the XT tweeter family utilizes two Tymphany technologies to deliver exceptional sound quality: the ring radiator patent, and the central waveguide patent. This model features a 4 ohm 25 mm voice coil, mounted in a neodymium magnet motor. The tweeter also features a rear chamber to create extended low frequency response. The faceplate features recessed mounting holes which minimizes reflections off of mounting screws.
Download PDF File
Peerless by Tymphany XT25TG30-04 Dual Ring Radiator Tweeter
PRODUCT INFO
This member of the XT tweeter family utilizes two Tymphany technologies to deliver exceptional sound quality: the ring radiator patent, and the central waveguide patent. This model features a 4 ohm 25mm voice coil, mounted in a ferrite magnet motor. The tweeter also features a rear chamber to create extended low frequency response. The faceplate features recessed mounting holes which minimizes reflections off of mounting screws
